CAT. No. AC1590

3-Way Optical TOSLINK Splitter
product image thumb
product image thumb
product image thumb
product image thumb

3-Way Optical TOSLINK Splitter

$59.95
Distribute your digital audio connection to multiple sources such as sound bars, headphones or your home theatre system.
Available

Description

1 Year Warranty
USB 2.0

Distribute your digital audio connection to multiple sources such as sound bars, headphones or your home theatre system. Allows a combined optical cable length of 40m with no audio quality loss. Audio format support for LPCM2.0, DTS and Dolby AC-3 with signal retiming for perfectly synced audio. USB powered and features voltage overload protection. Includes USB charging cable.

Specifications:
Inputs: 1 x TOSLINK (Optical)
Outputs: 3 x TOSLINK (Optical)
Frequency: 96KHz
Baud Rate: 16Mbps
Audio: LPCM 2.0, DTS, Dolby AC-3
Supported Cable Length: 40m (Total)
Power: 5VDC, 500mA (USB Mini B)
Power Consumption: 200mA (Max)
Dimensions: 60(W) x 54(D) x 20(H)mm

    Specifications

    A/V Switcher or Converter

    Input type
    		 Digital Audio
    Switcher/Converter Type
    		 Distribution Amplifier Splitter
    Input Connection
    		 TOSLINK
    Output Type
    		 Digital Audio
    Output Connection
    		 TOSLINK
    Power Requirement
    		 External Power Required
    Number of inputs
    		 1pc
    Maximum Total Cable Length (all in and out)
    		 40m
    Number of Outputs
    		 3pc

    Power from Plugpack

    DC Plugpack Voltage
    		 5V
    PSU Powers
    		 Main Product
    DC Current Draw
    		 500mA

    Audio Format

    Digital Audio Format
    		 LPCM 2.0, DTS, Dolby AC-3
    Maximum Signal Frequency
    		 96kHz
    Baud Rate
    		 16Mb/s

    Product Dimensions

    Height
    		 21mm
    Width
    		 62mm
    Depth
    		 58mm

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 13.5cm
    Packaged Width
    		 2.5cm
    Packaged Weight
    		 0.086kg
    Packaged Volume
    		 0.35438l
    Packaged Height
    		 10.5cm
    Warranty: 12 Months
