Spare HDMI Over IP Receiver to suit AC1752

$89.95
An additional receiver to expand your 150m 1080p HDMI Cat5e/Cat6 Over IP Extender (AC1752) to a screen in another room. Includes a mains power adaptor and infrared remote receiver for remote control operation.

Out of Stock

Description

1 Year Warranty

Enables you to expand your AC1752 150m 1080p HDMI Cat5e/Cat6 Over IP Extender to a screen in another room. Includes a mains power adaptor and infrared remote receiver so you can use your infrared remote control from the receiving point.

Features:
- HDMI 1.3, HDCP 1.4b compliant
- H.265/H.264 Compression
- Web Based Interface Control
- Expand your AC1752 HDMI Over IP Extender to multiple rooms
- Infrared Remote Control Extender


    Specifications

    A/V Switcher or Converter

    Switcher/Converter Type
    		 Balun Extender
    Additional Functions
    		 Remote Extender
    Output Type
    		 HDMI
    Output Connection
    		 HDMI Type-A, HDMI Type-A

    Power from Plugpack

    DC Plugpack Voltage
    		 5V, 5V
    Suitable PSU Included
    		 true, true
    Item Connection
    		 Barrel Plug
    PSU Powers
    		 Receiver, Receiver
    DC Current Draw
    		 1A, 1A

    Power from Plugpack (secondary)

    DC Plugpack Voltage
    		 5V, 5V
    Suitable PSU Included
    		 true, true
    PSU Powers
    		 Receiver, Receiver
    DC Current Draw
    		 1A, 1A

    Video Resolution

    HDMI Colour Space Compatibility
    		 RGB, YCbCr 4:4:4, YCbCr 4:2:2
    Maximum Vertical Resolution
    		 1920Pixel
    HDMI Version
    		 1.30000000
    Resolution Frequency
    		 60Hz
    Maximum Horizontal Resolution
    		 1200Pixel
    HDCP Version
    		 1.4b
    HDMI Maximum Colour Depth
    		 8b
    HDMI Maximum Data Rate
    		 6.75Gb/s
    Compliant with
    		 H.264 and H.265 Compression

    Audio Format

    Digital Audio Format
    		 LPCM
    Maximum Channel Support
    		 2ch
    Maximum Signal Frequency
    		 48kHz

    Infrared Remote Control Extender

    Maximum Range
    		 150m
    Extender Type
    		 Balun (UTP Cable)
    IR Signal Fequency Compatibility
    		 20kHz-60kHz

    Signal Extender Balun

    Signal Type
    		 HDMI
    Connecting Cable
    		 Cat5e UTP, Cat6 UTP
    Connecting Cable Termination
    		 RJ45
    Maximum Distance Between Baluns (cat6)
    		 150m
    Output Connection
    		 HDMI Type-A, HDMI Type-A
    Maximum Distance Between Baluns (cat5e)
    		 100m

    Product Dimensions

    Height
    		 17mm
    Dimensions for
    		 Receiver
    Width
    		 61mm
    Depth
    		 86mm
    Weight
    		 150g

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 20cm
    Packaged Width
    		 12cm
    Packaged Weight
    		 0.342kg
    Packaged Volume
    		 1.56l
    Packaged Height
    		 6.5cm
    Warranty: 12 Months
