CAT. No. HH8572

High Efficiency Fan Type Heatsink - 75mm Long
product image thumb
product image thumb

High Efficiency Fan Type Heatsink - 75mm Long

$11.95
Available in various lengths.- 105mm wide.- Thermal resistance 75mm unit 2.5° C/W;...
Available

Description

Available in various lengths.
- 105mm wide.
- Thermal resistance 75mm unit 2.2° C/W.

    Specifications

    Heatsinks

    Heatsink Thermal Resistance
    		 2.2°C/W
    Cooling Fan Mount Size
    		 33.5mm
    Heatsink Layout
    		 Fan
    Heatsink Fins
    		 5pc
    Sink Area Width
    		 72mm
    Component Mount Area Height
    		 25.5mm
    Heatsink Mounting Method
    		 Screw Down

    Product Dimensions

    Length
    		 72mm

    Packaged Dimensions

    Packaged Length
    		 12cm
    Packaged Width
    		 12.7cm
    Packaged Weight
    		 0.126kg
    Packaged Volume
    		 0.48768l
    Packaged Height
    		 3.2cm

    Product Availability

    Availability
    		 Stocked item
