CAT. No. MB3768

Portable 505Wh Power Station with 500W Inverter
product image thumb
product image thumb

Portable 505Wh Power Station with 500W Inverter

$849
This advanced multi-function power station keeps equipment running and charged from the internal 505Wh battery.

Out of Stock

Description

1 Year Warranty
USB 2.0
240V Mains Power
Batteries Included
Hazardous Materials

This advanced multi-function power station keeps your USB, 12V, and mains powered devices running when you are away from mains power. Use it during power outages, take camping or use it at your next outdoor gettogether to power your Smartphone, Tablet, media player, laptop, lights, or a small power tool. Multiple output port includes a USB Type-A port with Quick Charge™ and a USB Type-C port with Power Delivery to fast charge your USB devices. The internal Li-ion battery provides up to 505Wh of power (Equivalent to 140Ah portable USB power bank) and can be charged from the supplied mains power adaptor, cigarette lighter power adaptor, or from a solar panel (not included). An integrated BMS (Battery Management System) and MPPT (Maximum Power Point Tracking) advanced solar charge controller ensures you get the optimum charge. The LCD screen indicates the power input and output wattage, battery level, and any operational warnings such as overload or overheating.

FEATURES
- 500W Pure Sine Wave Inverter
- Battery Management System (BMS)
- Built-in MPPT Solar Charge Controller
- 505Wh Lithium Ion BAttery

SPECIFICATIONS
Inverter: 220V, 50Hz 500W continuous, 750W surge
Battery: 21.6V at 23.4Ah Li-ion (505Wh) built-in
Inputs/Outputs:
- USB Type-C with Power Delivery (Input/Output): 5-20V (30W max.)
- USB Type A with Quick Charge™ (Output): 5-9V (18W max.)
- USB Type A x 2 (Output): 5V @ 3.1A
- 12VDC 5.5mm Socket x 2 (Output): 12V/5A (60W max.)
- 12VDC Cigarette Lighter Socket (Output): 12V/10A (120W max.)
- DC Charging Port: 5.5mm DC Socket (11-24V, 72W max.)
- Solar Charging (PV input) Modular Connection: 11-26V (120W max.)


    Specifications

    Classified as dangerous goods


    DG Class
    9
    DG UN Number
    3480
    DG Pack Group
    II - Medium Danger
    DG Ship Name
    3480 - Lithium Ion Batteries
    DG Hazardous Chemical Code
    4W
    Battery Watt Hour Rating (Required for Lithium Batteries)
    505Wh

    Inverters


    Output Wave
    Pure sinewave

    AC Voltage Rating


    AC Frequency
    50Hz
    AC Voltage rating
    220V

    Power Rating


    Continuous Power
    500W
    Maximum Power
    750W

    DC Power Output


    Output Port 1 Details
    5.5mm DC Socket x 2: 12V 5A (60W max)
    Output Port 2 Details
    12VDC Cigarette Lighter Socket: 12V 10A (120W max)

    USB Power Bank


    Output 3 Details
    USB Type A (Output) x 2
    Output 2 Details
    USB Type A with Quick Chargeâ„¢ (Output) 18W max
    Output 1 Voltage
    5V-20V
    Output 1 Details
    USB Type-C with Power Delivery (Input/Output) 30W max
    Output 2 Voltage
    5V-9V
    Output 3 Voltage
    5V

    Power from rechargeable battery


    Solar Recharge Details
    Requires solar panel sold separately
    Type
    Lithium Ion
    Capacity
    23.4Ah
    Voltage
    21.6V

    Solar Charge Controllers and Regulators


    Charge Controller Technology
    Maximum Power Point Tracking (MPPT)

    Operating Temperature


    Operating Temperature
    -10°C-40°C

    Product Dimensions


    Height
    200mm
    Width
    300mm
    Depth
    193mm
    Weight
    5.8kg

    Product Availability


    Availability
    Stocked item

    Packaged Dimensions


    Packaged Length
    35.7cm
    Packaged Width
    25.5cm
    Packaged Weight
    7.206kg
    Packaged Volume
    27.94774l
    Packaged Height
    30.7cm
    Warranty: 12 Months
