CAT. No. MB3902

612VDC 0.87A 7-Step Intelligent Lead Acid and Lithium Battery Charger
product image thumb
product image thumb

612VDC 0.87A 7-Step Intelligent Lead Acid and Lithium Battery Charger

$39.95
With 7 charging modes, this versatile charger will keep your 6V or 12V Lithium (LiFePO4) or Sealed Lead Acid batteries in top condition.

Out of Stock

Description

1 Year Warranty

An intelligent battery charger to keep your batteries in peak working order. Suitable for 6V or 12V Lead Acid batteries between 1.2Ah - 26Ah, or 12.8V LiFePO4 from 2Ah to 15Ah. The seven charging modes keep batteries fully charged and in peak condition, and can also recover slightly sulfated batteries to increase battery life. LEDs on the front panel indicate the state of charge and a push button enables you to select the appropriate charge mode. The housing can be permanently mounted using the integrated mounting holes and the IP65 weatherproof rating means it can handle a little rain. The charger is mains powered, terminated to battery clips on a 1.8m lead, and features short circuit, overload, incorrect polarity, reverse battery, and safety timer protection.

Battery Support:
• Sealed, Gel, AGM or Flooded Lead (6/12V, 1.2Ah - 26Ah)
• LiFePO4 (12.8V, 2Ah - 15Ah)

Features:
- 6V/12V dual function charger
- Suitable for Lead Acid and LiFePO4 batteries
- 7 state intelligent charging modes
- Can recover slightly sulfated batteries

*Please note this charger will not recharge a completely flat battery

Specifications:
Charging Voltage:
Lead Acid: 7.3V/ 14.4V DC
LiFePO4: 12.8V/ 4 cells
Protection: Short circuit, Overload, Wrong polarity, Reverse Battery, Safety Timer


    Specifications

    Battery Charger


    Charger Output Voltage
    7.3V, 14.4V
    Additional Functions
    Short Circuit Protection, Overload Protection, Safety Timer Protection
    Connection Type
    Alligator Clips
    Charger Output Current
    800mA
    Type of Batteries
    Deep Cycle SLA, Lithium Ferrous Phosphate (LiFePO4)

    Mains powered


    Mains Max Current
    0.6A
    Frequency
    50Hz
    Mains Voltage Range
    220V-250V

    Ingress Protection Rating


    IP Rating
    IP65
    Dust/Particle Ingress Protection
    6 - Dust tight, no ingress of dust
    Liquid/Moisture Ingress Protection
    5 - Water jets

    Product Dimensions


    Length
    107mm
    Width
    63mm
    Depth
    34mm

    Product Availability


    Availability
    Stocked item

    Packaged Dimensions


    Packaged Length
    15.7cm
    Packaged Width
    8.8cm
    Packaged Weight
    0.288kg
    Packaged Volume
    1.0362l
    Packaged Height
    7.5cm
    Warranty: 12 Months
