CAT. No. MP5240

12V 2.5A DC to DC Uninterruptible Power Supply UPS
product image thumb
product image thumb

12V 2.5A DC to DC Uninterruptible Power Supply UPS

$83.95
Keep your equipment operating for longer allowing a safe shutdown during a power outage.

Out of Stock

Description

1 Year Warranty
Hazardous Materials

A compact DC UPS designed to connect inline with your ordinary 12VDC mains power adaptor. In the case of a power outage, the internal battery will keep your equipment operating for longer. Three interchangeable DC connectors are supplied to suit a range of devices such as a modem, network switch, router, video device, surveillance systems or lights. An integrated smart charger ensures the internal 18650 Li-ion batteries are charged, and adjusts the charge current based on the current draw to the device you are powering. The rated output is 2.5A at 12V but 3A can be provided for a short time. Four status LEDs indicate the UPS charge status, and safety features include over-charge, over-discharge, over-current, and short-circuit.

Features:
- 2.5A Output
- DC Power
- Built-in rechargeable Li-ion battery
- Integrated smart charger
- LED status indicators

DC Connectors (mm):
Input: 5.5OD x 2.1ID - Center Tip Positive
Output: 5.5OD x 2.5ID - Center Tip Positive

Adaptors (mm):
5.5OD/2.5ID Male to 5.5OD/2.1ID Female - Center Tip Positive
3.5OD/1.35ID Male to 5.5OD/2.5ID Female - Center Tip Positive
5.5OD/2.1ID Male to 3.5OD/1.35ID Female - Center Tip Positive

    Specifications

    DC Current Rating


    DC Current Surge Rating
    3A
    DC current rating
    2.5A

    DC Voltage Rating


    DC Voltage
    12.2V

    Rechargeable Battery


    Recharging Voltage
    11.8V-12.5V
    Standard Recharge Current
    0.8A

    Battery Packs and Batteries


    Battery Chemical Composition
    Lithium Ion
    Type of battery
    18650

    Product Dimensions


    Length
    138mm
    Height
    24mm
    Width
    60mm
    Weight
    260g

    Classified as dangerous goods


    DG Class
    9
    DG UN Number
    3481
    DG Pack Group
    II - Medium Danger
    DG Ship Name
    3481 - Lithium Ion Batteries Packed In Equipment
    DG Hazardous Chemical Code
    4W
    Battery Watt Hour Rating (Required for Lithium Batteries)
    7.4Wh

    Product Availability


    Availability
    Stocked item

    Packaged Dimensions


    Packaged Length
    19.7cm
    Packaged Width
    15.5cm
    Packaged Weight
    0.326kg
    Packaged Volume
    1.00766l
    Packaged Height
    3.3cm
    Warranty: 12 Months
