IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface
IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface
IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface
IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface

CAT. No. QM1571

IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface
product image thumb
product image thumb
product image thumb

IP67 True RMS Autoranging Cat IV DMM with Wireless USB Interface

$129
A quality true RMS multimeter with a wireless USB computer interface, non-contact voltage indicator, relative zero and data hold.

Out of Stock

Description

USB 2.0
Batteries Included
Wireless

A quality true RMS multimeter with a wireless USB computer interface, non-contact voltage indicator, relative zero and data hold. Double moulded housing is impact resistant and quite durable, and IP67 waterproof rating makes this DMM capable of even the harshest conditions. Wireless USB interface and included logging software allow for computer based live data logging whilst keeping your computer completely isolated and protected.

Features:

• IP67 waterproof
• True RMS
• Wireless USB interface
• PC logging software
• Auto power-off
• Backlight
• Non-contact voltage
• Data hold
• Diode test
• Autoranging
• Audible continuity
• 10A current range
• Double moulded case
• Display 4000 count
• Security Class Cat IV 600V
• Basic DCV accuracy 0.500%
• Temperature -20°C to +760°C (±3.0%)
• Ave/RMS True RMS
• Special features Wireless USB, IP67, True RMS, non-contact voltage

For More info on Digital Multimeters.

    Specifications

    Meter Safety Rating

    Safety Rating Max Volt
    		 600V
    Safety Rating Cat
    		 Cat IV

    Measures Voltage DC

    DC Voltage Accuracy
    		 0.50000000%
    DC Voltage Ranges
    		 400mV, 4V, 40V, 400V, 1000V

    Measures Voltage AC

    AC Voltage Ranges
    		 400mV, 4V, 40V, 400V, 1000V
    AC Voltage Accuracy
    		 0.80000000%

    Measures Current DC

    DC Current Accuracy
    		 1.20000000%
    DC Current Ranges
    		 4mA, 40mA, 400mA, 10A

    Measures Current AC

    AC Current Accuracy
    		 1.80000000%
    AC Current Ranges
    		 4mA, 40mA, 400mA, 10A

    Measures Resistance

    Resistance Ranges
    		 400?, 4k?, 40k?, 400k?, 40M?
    Resistance Accuracy
    		 0.80000000%

    Measures Capacitance

    Capacitance Accuracy
    		 3%
    Capacitance Ranges
    		 4nF, 40nF, 4µF, 40µF, 100µF

    Measures Frequency

    Frequency Ranges
    		 4kHz, 40kHz, 400Hz, 4MHz, 10Hz
    Frequency Accuracy
    		 1.50000000%

    Measures Temperature

    Measures in Celcius
    Outdoor / Exterior Scale
    		 -20°C-760°C
    Celcius Accuracy
    		 3%
    Measures in Fahrenheit

    Meter PC Interface

    Live Refresh
    DMM Control from PC

    Ingress Protection Rating

    IP Rating certificate
    Dust/Particle Ingress Protection
    		 6 - Dust tight, no ingress of dust
    Liquid/Moisture Ingress Protection
    		 7 - Immersion up to 1m

    Digital Multi-Meter

    Autorange
    True RMS

    Meter Data Control

    Data Hold
    Relative Measure

    Measures Continuity

    Continuity indicator
    		 Needle

    Meter Probes

    Probe rating voltage
    		 4000V
    Probe safety rating
    		 Cat IV

    Meter

    Input Protection Fuse
    		 10mA, 500mA
    Carry Case Included
    Casing
    		 Plastic
    Measures diode
    Meter Input Impedence
    		 10M?

    Power from disposable battery

    Batteries can be replaced by user
    Battery quantity
    		 1pc
    Batteries included
    How is battery compartment kept closed
    		 Clip and Screw
    Size / Shape
    		 9V
    Compartment location
    		 Internal / In-built

    Product Dimensions

    Length
    		 170mm
    Height
    		 50mm
    Width
    		 79mm

    Packaged Dimensions

    Packaged Length
    		 21.5cm
    Packaged Width
    		 15.5cm
    Packaged Weight
    		 0.718kg
    Packaged Volume
    		 1.9995l
    Packaged Height
    		 6cm

    Product Availability

    Availability
    		 Stocked item
    Warranty: 9999 Months
    Special terms or exclusions: Lifetime Warranty
