DPST IP56 Switch Black 250VAC 6A
DPST IP56 Switch Black 250VAC 6A
DPST IP56 Switch Black 250VAC 6A

CAT. No. SP0743

DPST IP56 Switch Black 250VAC 6A
product image thumb
product image thumb

DPST IP56 Switch Black 250VAC 6A

$9.95
- IP56 rated - DPST push on, push off - QC spade lugs. - Rated for 250VAC 6A - Mounting hole: 20mm...
Available

Description

• IP56 rated
• DPST push on, push off
• QC spade lugs.

    Specifications

    Electromechanical Switch

    Switch Function
    		 Locking On/Off
    Pole Throw Type
    		 DPST
    Switch Connection
    		 Solder Legs
    Switch Type
    		 Pushbutton
    Poles / Contacts
    		 2 pole
    Throws / Positions
    		 1pos
    Switch Colour Coded
    		 Black
    Mechanism Material
    		 Plastic

    Product Mounting

    Attachment / Securing Method
    		 Snap-in
    Round Mount Hole Diameter
    		 20mm
    Mounting Method
    		 Panel

    AC Voltage Rating

    AC Voltage rating
    		 250V

    AC Current Rating

    AC current rating
    		 6A

    Ingress Protection Rating

    IP Rating
    		 56
    IP Rating certificate
    Dust/Particle Ingress Protection
    		 5 - Dust protected, protected but some dust may enter
    Liquid/Moisture Ingress Protection
    		 6 - Powerful water jets

    Packaged Dimensions

    Packaged Length
    		 11.7cm
    Packaged Width
    		 7cm
    Packaged Weight
    		 0.01kg
    Packaged Volume
    		 0.2457l
    Packaged Height
    		 3cm

    Product Availability

    Availability
    		 Stocked item
