Unlike filament (FDM) type 3D printers, this resin printer uses UV light that passes through its 7K high resolution LCD screen to cure the resin layer by layer where it is needed. Compared to FDM this method produces a more detailed and smooth print with less visible print layers.

The Photon M3 Max is equipped with a large 7K resolution 13.6” monochrome LCD to produce detailed models up to 300mm high x 298mm wide x 164mm deep. The 6480 x 3600px resolution LCD provides a high 450:1 contrast ratio for 3D models in vivid detail with sharp edges and corners. A powerful light matrix using 84 bright LEDs provides over 90% light uniformity and 27K lux power density to each layer, which makes fast printing up to 60mm per hour possible. The brightness can be adjusted between 30-100% if necessary to help support specialty resins, and a dedicated and replaceable anti-scratch film above the screen itself makes the screen much more durable than rival printers.

To operate the printer, simply use the ANYCUBIC slicer software to prepare and save the model to the supplied USB thumb drive, which you insert into the USB port on the printer. Use the 4.3” touchscreen to operate and monitor your printer’s progress.

Other features include an auto resin filler & UV-blocking top cover.

Resin in multiple colours is sold separately.

Features:
• 13.6” 7K Monochrome LCD
• Dedicated & replaceable screen protector
• Fast Printing Speed
• High Quality Dual rail Z-axis

Specifications:
• Operation: 4.3 inch Touch Screen
• Software: ANYCUBIC Photon workshop
• Connectivity: USB
• Technology: LCD-based SLA
• Exposure Screen: 13.6 inch monochrome
• Light-source: Parallel matrix 84 x LEDs
• XY Res.: 6480 x 3600px (7K)
• Z Axis Res.: 0.01mm
• Layer Res.: 0.01-0.15mm
• Horz. Res.: 46µm
• Contrast Ratio: 450:1
• Printing Speed: MAX 50mm/h
• Rated Power: 120W
• Build Volume: 300(H) x 298(W) x 164(D)mm
• Material: 405nm UV Resin



NOTE: This is a special order line which is not stocked in all retail stores but can be ordered. Please call your local store to check if they have stock on hand.
