8 Gauge Figure 8 Power Cable - Sold per metre
8 Gauge Figure 8 Power Cable - Sold per metre
8 Gauge Figure 8 Power Cable - Sold per metre

CAT. No. WH3063

8 Gauge Figure 8 Power Cable - Sold per metre
product image thumb
product image thumb

8 Gauge Figure 8 Power Cable - Sold per metre

$13.95
For higher current applications where twin core cabling is required. Red and black colour for easy identification. - Conductor material: OFC...
Available

Description

For higher current applications where twin core cabling is required. Red & black colour for easy identification.

• Conductor material: OFC
• Insulation material: PVC
• Resistance @ 20°C: 0.00252ohm/m



    Specifications

    Packaged Dimensions

    Packaged Length
    		 100cm
    Packaged Width
    		 1.36cm
    Packaged Weight
    		 0.105kg
    Packaged Volume
    		 0.09112l
    Packaged Height
    		 0.67cm

    Wire and Cable

    Individual Conductor Strand Diameter
    		 0.12mm
    Resistance per Linear Metre
    		 2.4m?
    UV Resistant Cable
    Conductor Overall Diameter
    		 4.05mm
    Oil Resistant Wire
    Strand Weave Configuration
    		 (7x101) x 2
    Number of Conductor Strands
    		 707pc
    Outer Diameter
    		 6.7mm
    AWG
    		 8
    Halogen Free Wire
    Core Material
    		 Tin Plated Copper
    Number of Conductor Cores
    		 2pc
    Roll Length
    		 50m
    Wire Category
    		 hook up / power
    OFC wire
    Retail Sales Unit
    		 Metre
    Cross Sectional Area
    		 8mm²
    Twisted Cores

    Product colour

    Alternates available
    Colour
    		 Red

    DC Current Rating

    DC current rating
    		 56A

    Product Availability

    Availability
    		 Stocked item

    Downloads

    WH3063-dataSheetMain.pdf
