Hand Gesture Sensor Module for Arduino

$20.95
Control a project or build a game that recognises touchless hand gestures. Use it to create a lock that disarms with your own secret hand signals!
Available

Description

Control your project with touchless hand gestures. Onboard ambient light, RGB colour, and proximity sensors detect the hand movements in six different directions, then sends the data to your microcontroller over standard I2C communications. It has a detection range between 100 - 200mm, and uses UV and IR blocking filters to improve performance. The board measures just 20(W) x 12(H) x 11(D)mm including pins, and runs from 3.3V.

Features:
- Ambient Light & RGB Colour Sensing
- Proximity Sensing
- Gesture Detection
- I2C Interface


    Specifications

    Arduino Modules

    Required Supply Voltage
    		 3.3V

    Internal or Sub-part Dimensions

    Height
    		 12mm, 5mm
    Dimension details
    		 Module Dimensions (Including Pins), Detection Range
    Width
    		 20mm, 200mm
    Depth
    		 11mm

    Product Dimensions

    Length
    		 100mm
    Height
    		 12mm, 5mm
    Width
    		 20mm, 200mm
    Dimension details
    		 Module Dimensions (Including Pins), Detection Range

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 10cm
    Packaged Width
    		 10cm
    Packaged Weight
    		 0.01kg
    Packaged Volume
    		 0.07l
    Packaged Height
    		 0.7cm

    Downloads

      Articles
      Articles

    XC3742-manualMain.pdf
    XC3742-dataSheetMain.pdf
