While most of the modules used in the Arduino® world are 5V logic, some are 3.3V. And unfortunately, connecting them directly often results in letting out the magic smoke! This little module is the answer.
Available

Description

Arduino® Compatible

While most of the modules used in the Arduino® world are 5V logic, some are 3.3V. And unfortunately, connecting them directly often results in "letting out the smoke"! This little module is the answer. Provides two bi-directional channels to safely marry 3.3V with 5.0V. Drops straight into solder-less breadboard or can be soldered into your own PCBs.

Two bi-directional channels
12-pin DIL package


    Specifications

    Product Dimensions

    Height
    		 21mm
    Width
    		 35mm
    Depth
    		 31mm

    Packaged Dimensions

    Packaged Length
    		 10cm
    Packaged Width
    		 10cm
    Packaged Weight
    		 0.01kg
    Packaged Volume
    		 0.2l
    Packaged Height
    		 2cm

    Arduino Modules

    Required Supply Voltage
    		 3.3V
