5V Micro USB PoE Splitter
5V Micro USB PoE Splitter
5V Micro USB PoE Splitter

CAT. No. YN8416

5V Micro USB PoE Splitter
product image thumb
product image thumb

5V Micro USB PoE Splitter

$30.95
Channel ethernet and power down the same network cable.
Available

Description

Raspberry Pi Compatible
Arduino? Compatible


PoE allows your Ethernet and power to be channelled down the same Cat5 or Cat6 cable, easily providing power to remote devices. At the remote end, you need to get the power back out, hence the need for a PoE splitter. This unit provides 5V at up to 2.4A via a Micro USB plug, perfect for running a Raspberry Pi or PCDuino. A PoE injector or switch is needed at the other end of the cable to provide power.

Features:

 - Input Voltage: 44-57VDC
 - Output Voltage: 5VDC
 - Output Current: 2.4A
 - Ports: 1 x RJ45 Ethernet Plug
             1 x RJ45 Ethernet Socket
             1 x Micro USB Plug
 - PoE Standard: IEEE 802.3af
 - Network Speed: 10/100Mbps

Raspberry Pi is a trademark of the Raspberry Pi Foundation

    Specifications

    Product Dimensions

    Length
    		 300mm
    Cable length
    		 200m

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 15cm
    Packaged Width
    		 13cm
    Packaged Weight
    		 0.066kg
    Packaged Volume
    		 0.585l
    Packaged Height
    		 3cm
