50mm Thin (15mm) 12V DC
50mm Thin (15mm) 12V DC

CAT. No. YX2504

50mm Thin (15mm) 12V DC
product image thumb

50mm Thin (15mm) 12V DC

$21.95
Air Volume: 0.7 (m3/min), 16.6 (CFM)Bearing System: Sleeve bearingNoise: 33dbAVoltage: 12V DCInput: 2.28 wattsSize: 50 x 50 x 15mmImpeller: Plastic, f...
Available

Description

Features:

Air Volume: 0.7 (m3/min), 16.6 (CFM)
Noise: 33dbA
Input: 2.28 watts
Impeller: Plastic, fibreglass filled
Housing: Plastic, fibreglass filled
Current: 0.19


    Specifications

    Ventilation Fans

    Fan Operational Life at 25°C
    		 60000hr
    fan impeller material
    		 Plastic
    fan air volume cubic metres
    		 0.7m³/min
    fan bearing type
    		 Sleeve
    fan housing material
    		 Plastic
    fan air volume cubic feet
    		 23.8ft³/min
    fan number of wires
    		 2pc
    type of fan
    		 Axial
    fan RPM
    		 5500RPM
    fan noise
    		 30dB
    fan connector type
    		 Flyleads

    Power from Plugpack

    DC Plugpack Voltage
    		 12V
    DC Current Draw
    		 190mA

    Product Mounting

    Mounting Method
    		 Through Hole

    Product Dimensions

    Length
    		 50mm
    Width
    		 50mm
    Depth
    		 15mm

    Packaged Dimensions

    Packaged Length
    		 6.8cm
    Packaged Width
    		 6.6cm
    Packaged Weight
    		 0.04kg
    Packaged Volume
    		 0.13464l
    Packaged Height
    		 3cm

    Product Availability

    Availability
    		 Stocked item
